Većina običnih AP uređaja ne zadovoljava zahtjeve naprednih korisnika - nemaju sve potrebne mogućnosti, imaju premalo snage, brzine ili su preskupi i dizajnom nedopadljivi. Mikrotik je odlučio uzeti u obzir sve te zahtjeve i kreirati jedan uređaj koji će ih zadovoljiti a to je Mikrotik Chateau.
Radi se o veoma brzom, dual-band home AP-u sa CAT12 LTE modemom koji omogućava brzi internet bilo đe. LTE nije jedina opcija, Chateau ima 5x Gigabit ethernet portova i full-size USB port.
Pokreće ga Qualcom IPQ-4019 procesor koji radi na 716MHz i ima 256MB RAM-a.
Brzine koje LTE omogućava su do 600Mbps putem carrier-agregacije (CAT12 omogućava korištenje 3 banda u isto vrijeme), što je velika pogodnost u zagušenim okolinama sa velikim brojem LTE korisnika. Chateau LTE12 omogućava visoku efikasnost u područjima sa velikim brojem korisnika, kao i bolju konekciju u područjima sa slabim signalom.
Detaljne specifikacije uređaja
Specifications
| Details |
| Product code |
RBD53G-5HacD2HnD-TC&EG12-EA |
| Architecture |
ARM 32bit |
| CPU |
IPQ-4019 |
| CPU core count |
4 |
| CPU nominal frequency |
716 MHz |
| Switch chip model |
IPQ-4019 |
| Dimensions |
240 x 156 x 44 mm |
| RouterOS license |
4 |
| Operating System |
RouterOS v7 |
| Size of RAM |
256 MB |
| Storage size |
16 MB |
| Storage type |
FLASH |
| MTBF |
Approximately 200'000 hours at 25C |
| Tested ambient temperature |
-40°C to 70°C |
| IPsec hardware acceleration |
Yes |
Powering
| Details |
| Number of DC inputs |
1 (DC jack) |
| DC jack input Voltage |
12-28 V |
| Max power consumption |
23 W |
| Max power consumption without attachments |
17 W |
| Cooling type |
Passive |
Mobile
| Details |
| 3G Category |
R8 (42.2Mbps Downlink, 11.2Mbps Uplink) |
| 3G bands |
1 (2100MHz) / 5 (850MHz) / 8 (900MHz) / 3 (1800MHz) |
| LTE Category |
12 (600Mbps Downlink, 150Mbps Uplink) |
| LTE FDD bands |
1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 7 (2600MHz) / 8 (900 MHz) / 20 (800MHz) / 28 (700MHz) |
| LTE TDD bands |
38 (2600MHz) / 40 (2300MHz) / 41 (2500MHz) |
| TAC |
86056104 |
Wireless specifications
| Details |
| Wireless 2.4 GHz Max data rate |
300 Mbit/s |
| Wireless 2.4 GHz number of chains |
2 |
| Wireless 2.4 GHz standards |
802.11b/g/n |
| Antenna gain dBi for 2.4 GHz |
3 |
| Wireless 2.4 GHz chip model |
IPQ-4019 |
| Wireless 2.4 GHz generation |
Wi-Fi 4 |
| Wireless 5 GHz Max data rate |
867 Mbit/s |
| Wireless 5 GHz number of chains |
2 |
| Wireless 5 GHz standards |
802.11a/n/ac |
| Antenna gain dBi for 5 GHz |
4 |
| Wireless 5 GHz chip model |
IPQ-4019 |
| Wireless 5 GHz generation |
Wi-Fi 5 |
Ethernet
| Details |
| 10/100/1000 Ethernet ports |
5 |
Peripherals
| Details |
| Number of SIM slots |
1 Modem (Micro SIM) |
| Number of USB ports |
1 |
| USB Power Reset |
Yes |
| USB slot type |
USB type A |
| Max USB current (A) |
1 |
Other
Certification & Approvals
| Details |
| Certification |
CE, EAC, ROHS |
| IP |
IP20 |
Wireless specifications
| 2.4 GHz |
Transmit (dBm) |
Receive Sensitivity |
| 1MBit/s |
25 |
-100 |
| 11MBit/s |
25 |
-94 |
| 6MBit/s |
26 |
-96 |
| 54MBit/s |
23 |
-78 |
| MCS0 |
26 |
-96 |
| MCS7 |
22 |
-73 |
| 5 GHz |
Transmit (dBm) |
Receive Sensitivity |
| 6MBit/s |
26 |
-96 |
| 54MBit/s |
22 |
-80 |
| MCS0 |
26 |
-96 |
| MCS7 |
21 |
-75 |
| MCS9 |
19 |
-70 |
