MikroTik wAP ax (model wAPG-5HaxD2HaxD) je bežični ruter dizajniran za rad u teškim spoljnim uslovima, sa otpornim IP67 kućištem koje omogućava njegovu upotrebu na otvorenom. Podržava najnoviji Wi-Fi 6 standard (802.11ax), pružajući brže i efikasnije bežično povezivanje. Ima dva dual-band Wi-Fi priključka (2.4 GHz i 5 GHz) i može raditi kao AP, klijent ili bežični most. Pored toga, opremljen je sa gigabitnim Ethernet portovima i snažnim procesorom, što ga čini pogodnim za upotrebu u zahtjevnijim mrežama. Ovaj uređaj je idealan za prekrivanje Wi-Fi signalom na velikim površinama, kao što su dvorišta, terase ili industrijski prostori.
Specifications
| Details |
| Product code |
wAPG-5HaxD2HaxD |
| Architecture |
ARM |
| CPU |
IPQ-5010 |
| CPU core count |
2 |
| CPU nominal frequency |
800 MHz |
| RouterOS license |
4 |
| Operating System |
RouterOS v7 |
| Size of RAM |
256 MB |
| Storage size |
128 MB |
| Storage type |
NAND |
| MTBF |
Approximately 100'000 hours at 25C |
| Tested ambient temperature |
-40°C to 70°C |
| |
|
Wireless capabilities
| Details |
| Wireless 2.4 GHz Max data rate |
574 Mbit/s |
| Wireless 2.4 GHz number of chains |
2 |
| Wireless 2.4 GHz standards |
802.11b/g/n/ax |
| Antenna gain dBi for 2.4 GHz |
7 |
| Wireless 2.4 GHz chip model |
IPQ-5010 |
| Wireless 2.4 GHz generation |
Wi-Fi 6 |
| Wireless 5 GHz Max data rate |
2400 Mbit/s |
| Wireless 5 GHz number of chains |
2 |
| Wireless 5 GHz standards |
802.11a/n/ac/ax |
| Antenna gain dBi for 5 GHz |
7 |
| Wireless 5 GHz chip model |
QCN-6102 |
| Wireless 5 GHz generation |
Wi-Fi 6 |
| WiFi speed |
AX3000 |
Ethernet
| Details |
| 10/100/1000 Ethernet ports |
2 |
Powering
| Details |
| Number of DC inputs |
2 (DC jack, PoE-IN) |
| DC jack input Voltage |
12-57 V |
| Max power consumption |
9 W |
| Max power consumption without attachments |
9 W |
| Cooling type |
Passive |
| PoE in |
802.3af/at |
| PoE in input Voltage |
18-57 V |
Certification & Approvals
| Details |
| Certification |
CE, FCC, IC, EAC, ROHS |
| IP |
54 |
Other
| Details |
| CPU temperature monitor |
Yes |
| PCB temperature monitor |
Yes |
| Voltage Monitor |
Yes |
