Ubiquiti U6 IN-WALL

280.24€
*Cijena sa uračunatim popustom i PDV-om, za jednokratna plaćanja.


Podijeli:

Ubiquiti U6 IN-WALL je zidni access point. Ova pristupna tačka podržava Wi-Fi 6 generacije i radi u pojasima od 2,4GHz i 5GHz. Ukupna brzina protoka je do 5,3 Gbps. Uređaj je opremljen sa jednim PoE ethernet portom i četiri gigabit ethernet porta. Uređajem je moguće upravljati pomoću aplikacije UniFi Network.

Mechanical
Dimensions 139.66 x 96 x 31.19 mm (5.5 x 3.78 x 1.28")
Weight 460 g (1.01 lb)
Enclosure materials Plastic, aluminum
Mount material Aluminum
Hardware
Networking interface (1) Data-in: 1GbE RJ45 port
(4) Data-out: 1GbE RJ45 ports
Management interface Ethernet
Bluetooth
PoE interface (1) PoE in (PoE output not used)
(1) PoE out (Requires a PoE+ switch)
Power method PoE
Power supply UniFi PoE switch
48V, 0.5A PoE adapter (Optional)
Max. power consumption Excluding PoE output: 13.5W
Max PoE wattage per port by PSE 15.4W*
*Requires a PoE+ switch
Voltage range PoE mode 44—57V DC
Max. TX power
2.4 GHz
5 GHz

22 dBm
26 dBm
MIMO
2.4 GHz
5 GHz

2 x 2 (UL MU-MIMO)
4 x 4 (DL/UL MU-MIMO)
Throughput rate
2.4 GHz
5 GHz

573.5 Mbps
4.8 Gbps
Antenna gain
2.4 GHz
5 GHz

5 dBi
5.9 dBi
LED White/blue
Button Factory reset
Operating temperature -30 to 60° C (-22 to 140° F)
Operating humidity 5 to 95% noncondensing
Certifications CE, FCC, IC
Software
WiFi standards 802.11a/b/g
WiFi 4/WiFi 5/WiFi 6
Wireless security WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
BSSID 8 per radio
VLAN 802.1Q
Advanced QoS Per-user rate limiting
Guest traffic isolation Supported
Concurrent clients 300+
Zero-wait DFS Yes*
*Supported with upcoming firmware versions.
Supported Data Rates
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (WiFi 4) 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)
802.11ac (WiFi 5) 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
802.11ax (WiFi 6) 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
Application Requirements
UniFi Network Version 6.4.52 and later
